| System | |
| Continuous Power | 3000W |
| Surge Power | 6000W |
| Output Voltage | 100/110/120 VAC; 220/230/240 VAC |
| Output Waveform | Modified Sine Wave |
| Total Harmonic Distortion | - |
| Output USB Port | - |
| Standby Current (Normal Mode) | DC 12V: < 0.7A; DC 24V: < 0.5A |
| Standby Current (Saving Mode) | - |
| Output Regulation | < ±5% Intelligent PWM |
| Output Frequency | 50/55/60 Hz Crystal Controlled |
| Input Voltage | DC 12V: 10~15V; DC 24V: 20~30V |
| Input Voltage Auto-Switch | - |
| Efficiency | > 85% |
| Protection | |
| Input Type Auto-Detection | YES |
| Input Polarity Reverse Protection | Fuse |
| Input Low Voltage Protection | DC 12V: < 10.5V Pre-Alarm, < 9.5V Shutdown & Alarm DC 24V: < 21.5V Pre-Alarm, < 20V Shutdown & Alarm |
| Output Short Circuit Protection | YES |
| Output Overheat Protection | > 60°C Pre-Alarm, > 65°C Shutdown & Alarm |
| Output Overload Protection | > 3000W Pre-Alarm, > 3200W Shutdown & Alarm |
| Cooling | Intelligent Fan |
| Mechanical | |
| Fuse | DC 12V: 30A x 16PCS; DC 24V: 15A x 16PCS |
| AC Outlets | EU: 2; USA: 3 |
| Dimension (L x W x H) | 360 x 169 x 152 mm |
| Net Weight | 6.9 kg |
| RC (Standard) Accessory | YES |
| RC (LED) Accessory | - |
| Battery Charger | |
| Charging Current | DC 12V: 10A DC 24V: 5A |
| Battery Full Detection | YES |
| Power Auto-Switch | AC LINE -> INVERTER INVERTER -> AC LINE |
| Switching Time | AC LINE -> INVERTER: < 16ms INVERTER -> AC LINE: < 16ms |
